Focus on the field of micro powder grinding !
Processing ability: 1-45 t/h
Fineness: 325-3000 mesh
Max feeding size: 10-25mm
Range of application: Fluorite, bamboo, gypsum, talc, dolomite, silica, graphite, mica, limestone, calcium carbonate, quartz, calcite, kaolin, bamboo, carbon black, bentonite, illite, pyrophyllite, vermiculite, sepiolite...
Table of Contents
Fluorite ultrafine powder grinding mill is a specialized equipment for grinding and processing fluorite powder. Fluorite is a mineral with a wide range of uses, including in the chemical, metallurgical, ceramic, and glass industries.
The fluorite ultrafine powder grinding mill uses advanced technology and combines various mechanical and chemical properties of fluorite to create a highly efficient grinding machine. It is designed to produce fine and ultrafine powders with a particle size of up to 3000 mesh.
The mill consists of a grinding chamber, grinding rollers, grinding ring, and a motor. The fluorite is fed into the grinding chamber through a hopper and is ground by the grinding rollers and ring. The ground powder is collected in a cyclone separator and discharged through a discharge valve.
The advantages of the fluorite ultrafine powder grinding mill include its high efficiency, low energy consumption, low noise level, and easy operation and maintenance. It is an ideal equipment for processing and grinding high-quality fluorite powder.
1. High efficiency: The grinding mill is designed with a scientific and reasonable structure, which can effectively improve the grinding efficiency and reduce the energy consumption.
2. Large capacity: The fluorite ultrafine powder grinding mill has a large capacity, which can meet the needs of large-scale production.
3. Environmental protection: The grinding mill uses advanced dust removal technology, which can effectively control the dust pollution and protect the environment.
4. High automation: The grinding mill adopts advanced control system, which can realize automatic control of the production process, reduce manual intervention, and improve production efficiency.
5. High precision: The grinding mill is equipped with a high-precision classification system, which can accurately classify the materials and ensure the uniformity of the particle size distribution of the final product.
6. Low maintenance cost: The grinding mill is designed with a simple and reliable structure, which can reduce the maintenance cost and prolong the service life of the equipment.
The working principle of this fluorite ultrafine powder grinding mill is based on the grinding and impacting forces generated by the rotation of its grinding ring and rollers.
1. The raw fluorite material is evenly and continuously sent into the grinding chamber by the electromagnetic vibrating feeder.
2. The material is then crushed and ground by the grinding roller and grinding ring, which rotate at a high speed.
3. The centrifugal force generated by the rotation of the grinding roller pushes the material towards the grinding ring, and the grinding ring presses the material against the grinding roller.
4. This action creates a strong grinding and impacting force, which helps to crush and grind the fluorite material into fine powder.
5. The ground powder is then blown into the powder concentrator by the airflow system, where it is separated from the air and collected in the product collector.
6. The purified air is discharged through the exhaust pipe, and the powder is discharged from the product collector.
7. The fineness of the final product can be adjusted by adjusting the rotational speed of the classifier.
In summary, the working principle of fluorite ultrafine powder grinding mill is to use the grinding and impacting forces generated by the rotation of the grinding ring and rollers to crush and grind the raw fluorite material into fine powder, which is then separated from the air and collected in the product collector.
HGM series of ultrafine fluorite powder grinding mill is available in the following models:
| Model | HGM80 | HGM80A | HGM90L | HGM100L-Ⅱ | HGM100P | HGM125L | HGM1680L |
| Ring Diameter(mm) | 800 | 800 | 900 | 1000 | 1000 | 1250 | 1680 |
| Ring Number (PCS) | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| Input Size (mm) | ≤10 | ≤10 | ≤10 | ≤15 | ≤15 | ≤20 | ≤20 |
| Adjustable range of finished product (mesh) | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 |
| Capacity (t/h) | 0.5-5.5 | 0.5-5.5 | 0.8-6.5 | 1.2-10 | 1.2-11 | 2.5-20 | 5-45 |
| Outlet Size L*W*H (mm) | 8605*4139*6050 | 10454*3393*6626 | 11735*3952*7525 | 14507*3633*7562 | 14362*4200*7562 | 19261*4406*8591 | 25067*5414*9007 |
| Main motor power (kw) | 75 | 75 | 55*2 | 132/75*2 | 132/75*2 | 185 | 315 |
You can choose according to your actual needs. If you are not sure what type of mill you need, you can click here to leave us a message. Later, our professional sales manager will get in touch with you, and he will make a reasonable recommendation for you according to your actual situation.
Fluorite powder is a mineral powder made from the mineral fluorite, also known as calcium fluoride (CaF2). It is a natural mineral that occurs in a wide range of colors including purple, green, yellow, blue, and clear.
Fluorite powder is produced by crushing and grinding fluorite ore, and can be used in a variety of industrial applications such as metallurgy, ceramics, glass, and chemical production. It is also used in the production of hydrofluoric acid, which is used in the semiconductor and pharmaceutical industries.
In addition to its industrial uses, fluorite powder is also used in jewelry-making and as a decorative material due to its beautiful colors and unique fluorescence under ultraviolet light.
1. Clirik is a well-known manufacturer of powder processing equipment, including crusher,ultrafine grinding mills, packing powder, coating machine and so on stone processing equipment.
2. Our fluorite ultrafine powder grinding mill is designed specifically for the grinding of fluorite, and it uses advanced technology and high-quality materials to ensure efficient and precise grinding.
3. We can not only provide you with high quality mine grinding equipment, but also can provide you with high quality service.
Pre-sale service：
1.Clirik provides a variety of mining equipment for you to choose from.
2.Clirik will recommend suitable production lines and grinding equipment to you according to your site.
3.Clirik customizes the logo and color of the grinding equipment according to your company image.
4.Clirik provides third party inspection to ensure the quality of your grinding equipment.
After-sales service：
1.Clirik provides you with online installation and uses videos.
2.Clirik will provide you with technicians to install and debug the grinding equipment.
3.Clirik trains you the technicians who use and maintain the grinding equipment.
4.Clirik provides you with a one-year warranty and lifetime service for grinding equipment.
Shanghai Clirik Machine Co., Ltd. has a variety of flourite powder grinding mills, such as: HGM series micro powder grinding mill, YGM series high pressure suspension grinding mill, CLUM series ultrafine vertical roller mill, CLRM series enhanced roller grinding mill.
