Carbon black ultrafine powder grinding mill

Processing ability: 1-45 t/h

Fineness: 325-2500mesh

Max feeding size: 10-25mm

Range of application: Carbon black, gypsum, talc, dolomite, silica, graphite, mica, limestone, calcium carbonate, quartz, calcite, kaolin, fluorite, bamboo, bentonite, illite, pyrophyllite, vermiculite, sepiolite...

  • +8613917147829

Product overview of carbon black ultrafine powder grinding mill

Carbon black ultrafine powder grinding mill is a device that breaks solid carbon black into powder by grinding. It is also called (three-ring four-ring) medium-speed ring roller micro powder grinding machine. It adopts a graded continuous grinding method to grind the material multiple times at the same time to truly realize ultra-fine powder grinding mill. It is usually used in metallurgy, building materials, chemicals and mine industries.

Carbon Black Ultrafine Powder Grinding Mill

Model: HGM80, HGM90, HGM100, HGM125, HGM1680

Adjustable fineness: 325-2500 mesh

Output: 1-45 t/h

Material: Non-flammable, non-explosive, brittle material with Mohs hardness ≤6. It is mainly used for high-fine powder processing of non-metallic ores such as calcite, kaolin, dolomite, barite, limestone, and marble.

Features: Safe and stable, high efficiency and energy saving, simple operation, wide application range, long service life than ordinary mills, environmental protection and pollution-free

Carbon black ultrafine powder grinding mill
Carbon black ultrafine powder grinding mill

Product parameter of carbon black ultrafine powder grinding mill

Parameter 1

Model HGM80 HGM80A HGM90L HGM100L-Ⅱ HGM100P HGM125L HGM1680L
Ring Diameter(mm) 800 800 900 1000 1000 1250 1680
Ring Number (PCS) 3 3 4 4 4 4 4
Input Size (mm) ≤10 ≤10 ≤10 ≤15 ≤15 ≤20 ≤20
Adjustable range of finished product (mesh) 150-3000 150-3000 150-3000 150-3000 150-3000 150-3000 150-3000
Capacity (t/h) 0.5-5.5 0.5-5.5 0.8-6.5 1.2-10 1.2-11 2.5-20 5-45
Outlet Size L*W*H (mm) 8605*4139*6050 10454*3393*6626 11735*3952*7525 14507*3633*7562 14362*4200*7562 19261*4406*8591 25067*5414*9007
Main motor power (kw) 75 75 55*2 132/75*2 132/75*2 185 315

Parameter 2

Unit kw HGM80 HGM90L HGM100L-Ⅱ HGM100P HGM125L HGM1680L
Main unit 75 2*45 132-150 132-150 185-200 315
Classifier 18.5 18.5-30 30-37 30-37 75 132
Blower 45 55 75 75 2*45-2*55 2*75-2*90
Crusher 18.5 18.5 18.5 18.5 45 75
Bucket Elevator 3 3 4 4 4 7.5
Belt Conveyor Feeder 1.5 1.5 1.5 1.5 1.5 2
Discharging Valve 2*0.75 1.1 1.1 1.1 1.5 2*1.5
Air Compressor 11 15 22 22 37 55

Working principle of carbon black ultrafine powder grinding mill

The carbon black ultrafine powder grinding mill production line usually includes mainly consist of main unit, crusher, classifier, powder collector, dust cleaner, blower, muffler, sound-proof room, crusher, bucket elevator, storage hopper, and vibrating feeder.

HGM Ultrafine Powder Grinding MILL
HGM Ultrafine Powder Grinding MILL
Jaw Crusher
Jaw Crusher
TH Bucket Elevator
TH Bucket Elevator

After crusher by hammer crusher, the large materials become small ones and are sent to storage hopper by elevator, and then evenly sent to the upper distribution plate of the turn plate of the turn plate by vibrating feeder and sloping feeding pipe.

When the carbon black ultrafine powder grinding mill is at work, the main bearing and each dial are driven by electricity of main equipment through reducer, and all the grinding rollers are rolling in the ring channels driving by dial through plunger. The materials are driven to the edge of the turn plate by the centrifugal force and fall down into the grinding chambers where the materials are repeatedly pressed. crushed and grinded by the rollers. Then the materials fall into multiple layers and to be crushed and ground continuously to micro powder.

The high-pressure air blower constantly inhales air within the grinding mill and, in turn, the airflow with crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to the mill for being around while the qualified particle size mixed with air will go into the cyclone powder collector.

Most of the qualified powders will fall and exit from the discharging valve at the bottom;a small proportion of the fine powders, with airflow, moves to the dust cleaner, and clings to the surface of the filter bags. At the same time, the fine powders, with airflow, moves to by the sudden vibration of the filter bags, which is caused by the instantly ejected high-pressure gas controlled by the pulse valve. The materials from the above two lots are sent by the conveyor at the bottom to get finished powders packed. In addition, filtered clean air will be emitted from the air outlet of muffler in the end.

Product advantage of carbon black ultrafine powder grinding mill

1. Carbon black ultrafine powder grinding mill with the same fineness and power consumption, the output is 30% higher than that of jet mill and ball mill.

2. Low wear parts loss, all wear parts are made of high wear resistant materials, prolong the service life of grinding equipment.

3. The fineness of the finished product can reach 150-2500 mesh range.

4. Environmental protection, the use of high efficiency pulse type dust collector, dust-free in the operation process of pollution, equipped with muffler and anechoic chamber, reduce noise, in line with international environmental standards of production, to the surrounding environment has played a role in environmental protection.

Carbon black
Carbon black

Carbon black

Carbon black is a kind of amorphous carbon, which is a light, loose and extremely fine black powder with a very large surface area ranging from 10 to 3000m2/g. It is a carbonaceous substance (coal, natural gas, heavy oil, fuel oil, etc.) are the products obtained by incomplete combustion or thermal decomposition under the condition of insufficient air.

Carbon black powder can be applied to tires, plastics, food contact grades, batteries, high performance coatings, rubber goods, pipe, agricultural irrigation, mulch films and greenhouse coverings, automotive skin contact, wire and cable, toner and printing inks.

Introduction manufacturer of carbon black ultrafine powder grinding mill

SHANGHAI CLIRIK MACHINERY CO., LTD as a professional enterprise which is specializing in research, manufacture and sales all kinds of mining equipment, We have many agents sell our products all over the world.

Our products are widely used in the industry of mining, construction materials, chemicals, metallurgy, transportation, hydraulic engineering and so on. Specially we independently developed carbon black HGM series powder grinding mill,

which are not only renowned in domestic market, but also have been sold widely in Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, and America, etc.

We still insist on the communication and cooperation with prestigious scientific research institutions from both home and abroad to make our development ability always is in the domestic front. We’ll always follow your steps, pursue your value and achieve your profit.
